Page #9 background imageLoading...
Page #9 background image
DISPLAY
A B
DG EF C
A. Timer / Temperature
B. Heat-up and residual heat indicator
C. Food Sensor (selected models only)
D. Door lock (selected models only)
E. Hours / minutes
F. Demo Mode
G. Clock functions
BEFORE FIRST USE
WARNING! Refer to Safety chapters.
Set the time before you use the oven.
INITIAL CLEANING
Step 1 Step 2 Step 3
Remove all accessories and re-
movable shelf supports from
the oven.
Clean the oven and the acces-
sories with a soft cloth, warm
water and a mild detergent.
Place the accessories and the
removable shelf supports in
the oven.
INITIAL PREHEATING
Preheat the empty oven before the first use.
Step 1 Remove all accessories and removable shelf supports from the oven.
Step 2
Set the maximum temperature for the function: .
Let the oven operate for 1 h.
Step 3
Set the maximum temperature for the function: .
Let the oven operate for 15 min.
The oven can emit an odour and smoke during preheating. Make sure that the room is ventilated.
DAILY USE
WARNING! Refer to Safety chapters.
HOW TO SET: HEATING FUNCTION
Step 1 Turn the knob for the heating func-
tions to select a heating function.
Step 2 Turn the control knob to select the
temperature.
Step 3 When the cooking ends, turn the
knobs to the off position to turn off
the oven.
HEAT-UP INDICATOR
When the oven function operates, the bars in the
display
appear one by one when the
temperature in the oven increases, and disappear
when it decreases.
9
