Zebra MC2200 User Manual

MC2200/MC2700 Quick Start Guide
8
Installing the Battery
NOTE: User modification of the device, particularly in the battery well, such as labels, asset tags, engravings, stickers, etc.,
may compromise the intended performance of the device or accessories. Performance levels such as sealing (Ingress Pro-
tection (IP)), impact performance (drop and tumble), functionality, temperature resistance, etc. could be effected. DO NOT
put any labels, asset tags, engravings, stickers, etc. in the battery well.
1. Insert the battery, top first, into the battery compartment in the back of the device.
2. Press the bottom of the battery down, into the battery compartment, until the battery release button snaps
into place.
Removing the Battery
NOTE: It is recommended to remove the optional trigger handle and/or hand strap prior to battery removal.
1. Holding both the top and bottom of the battery, press the battery release button on the bottom of the battery
with your thumb.
MN-004030-02EN_mc2200-mc2700-qsg-en.fm Page 8 Monday, November 9, 2020 6:06 PM

Zebra MC2200 Specifications

General

Display diagonal	4 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	800 x 480 pixels
Flash memory	32 GB
Internal memory	3 GB
Internal memory type	-
Compatible memory cards	MicroSD (TransFlash), SDXC
Processor model	660
Processor family	Snapdragon
Processor frequency	1.8 GHz
Processor manufacturer	Qualcomm
Operating system installed	Android
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Security algorithms	WPA2-Enterprise, WPA3-Enterprise
USB 2.0 ports quantity	1
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	3500 mAh
Scanner type	1D/2D
Product color	Black
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	38.5 mm
Width	70 mm
Height	200.5 mm
Weight	296 g
