Zero PORTA User Manual

zero
HOME AUTOMATION
PG7
ZPORTAV230 | CONTROL PANEL | PORTA 230V
SAFETY INSTRUCTIONS
STANDARDS TO FOLLOW
• To ensure the safety of people, it is important that you
read all the following instrucons. Incorrect installaon or
incorrect use of the product can cause physical injury and
material damage.
• Keep these instrucons in a safe place for future refe-
rence.
• This product was designed and produced strictly for the
use indicated in this manual. Any other use, not expres-
sly indicated here, could compromise the good condion/
operaon of the product and/or be a source of danger.
• ZERO SRLS is not responsible for the improper use of the
product, or other use than that for which it was designed.
• ZERO SRLS is not responsible if safety standards were
not taken into account when installing the equipment, or
for any deformaon that may occur to it.
• ZERO SRLS is not responsible for the safety and proper
operaon when using components not sold by them.
• Do not make any modicaons to the operator compo-
nents and / or their accessories.
• Before installaon unplug the automasm from the
source of power.
• The installer must inform the client how to handle the
product in case of emergency and provide this manual to
user.
• Keep remote controls away from children, to prevent
the automated system from being acvated involuntarily.
• The customer shall not, under any circumstances, at-
tempt to repair or tune the automasm. Must call quali-
ed technician only.
• Connect the automasm to a 230V plug with ground
wire.
• Control board for indoor use.
THE CONTROL BOARD
TECHNICAL SPECIFICATIONS
Power supply: 230V 50/60Hz
Motor’s output: AC230V 1350 W max
Aux. accessories
output:
AC12V-1W- 80mA máx
Working temperature: -20°C a +50°C
Radio Receptor: Incorporated 433,92 Mhz
OP Transmiers: Rolling Code
Max. memory capacity: 50 codes max
CONNECTOR’S DESCRIPTION
CN1 Connector
01 • LINE INPUT NEUTRAL
02 • LINE INPUT PHASE 230V
03 • MOTOR OUTPUT CLOSE
04 • MOTOR OUTPUT OPEN
05 • MOTOR COM
CN2 Connector
06 • POWER SUPPLY OUTPUT 12Vdc
07 • POWER SUPPLY OUTPUT 0Vdc
08 • PHOTOCELLS INPUT (NC) - PHOTO
09 • COM CONNECTION
10 • OPEN PUSH BUTTON (NO) - START
11 • SAFETY EDGE 8.2KOHM (NC)
OPTION (conguraon with brake relese PORTA SB)
12 • BRAKE INPUT (+12V)
13 • COM CONNECTION
14 • BATTERY (0V)
15 • BATTERY (12V)
PROGRAMMING PRE-RECOMENDATIONS
Before proceeding to the control board conguraon,
note the following points listed in the table below in order
to beer understand the control board funcon:
Motor:
03 and 04 The motor phases must be connected in these
two terminals. If the motor direcon is the opposite to the
desired simply switch the two wires to reverse direcon.
Security circuit - Photocells:
09 (COM) and 08 This circuit allows connecon of all pho-
tocells types. This device intervenes only during closure.
In pause me When it is acvated during closing maneu-
vers, it stops and starts a complete automasm opening.
Mecanic push-buon:
09 (COM) and 10 This circuit allows the connecon of
mechanical push-buons with two buon for opening
and closing. NOTA You can, with a one buon’s push-but-
ton , control the opening and closing of the automaon
in step mode (open-stop-close-stop (...) always with the
same buon.
