Zip Hydroboil Plus 5 Litre White HP005 User Manual

Page 7 of 16 Zip Hydroboil Plus - Installation & Operating Instructions - 86584UK - May 2012 v1.00
Wall Mounting Template Dimensions
274 (1.5 L & 3.O L)
304 (5.0 L & 7.5 L)
65 CLEAR
56
POSITIONING PIN
EXTERNAL PLUMBING
ELECTRICAL WIRING
POSITION
INTERNAL PLUMBING
72
15
25
35
42
COLD
INLET
VENT
BENCH TOP
416 3.O L
448 5.O L
561 7.5 L
38 (1.5 L & 3.O L)
53 (5.0 L & 7.5 L)
150
CLEAR
19
20
End of life Disposal
In order to help preserve our environment we ask that you dispose of this
product correctly. Please contact Zip customer services for advice on 0845
602 4533
Wall Mounting Template Dimensions

Zip Hydroboil Plus 5 Litre White HP005 Specifications

General

Brand	Zip
Model	Hydroboil Plus 5 Litre White HP005
Category	Water Heater
Language	English
