Zip Tudor User Manual

Zip Tudor - Installation & Operating Instructions - 81333 - February 2010 V2 Page 5
Installation Procedure Continued
Quick Installation Guide
Cold Water Supply
Isolation Valve (not supplied)
Restrictaflow see page 4
Step Four
Connecting
see Page 4.
Step Five
Commissioning.
see page 4
before turning power on
Step Three
Fasten heater to wall
see page 3
Step Two
Position heater < 1 Metre from tap
see page 3
Step One
Install approved vented tapware
see page 3
Tudor Heater
WIDTH
255 (5L)
310 (10L)
HEIGHT
390 (5L)
455 (10L)
100
70
DEPTH
215 (5L)
265 (10L)
140
COLD
IN
HOT
OUT
UNDER SINK INSTALLATION
III
III
I
E
*
ZIP
ZIP
T
udor
udor
140 (5L)
180 (10L)
250 (5L)
275 (10L)
SIDE VIEWFRONT VIEW
FIXING HOLES
WALL
Wall fixing details
4 mm
gap
Anchor
Bolt
Screw
Head
Wall
265 (5L)
355 (10L)
III
III
I
E
*
T
udor
udor
DEPTH
215 (5L)
265 (10L)
WIDTH
255 (5L)
310 (10L)
HEIGHT
390 (5L)
455 (10L)
SIDE VIEW
100
140
70
FRONT VIEW
COLD
IN
ABOVE SINK INSTALLATION
WALL
125 (5L)
100 (10L)
FIXING HOLES
Open Outlet
HOT OUT

Zip Tudor Specifications

General

Brand	Zip
Model	Tudor
Category	Water Heater
Language	English
