ZLAN ZLAN5143I User Manual

Shanghai ZLAN Information Technology Co., Ltd Tel: +86-17321037177 http://www.zlmcu.com
7
be five types: None, Odd, Even, Mark, Space, support CTS/RTS hardware flow
control. If need to support 460800bps, choose model ZLAN5142I.
8) Rich single light: power, wiring connection, TCP connection, data activity.
9) Support multiple TCP connection, as a TCP Server, can be connected with 40
clients. As a TCP Client, can connect with 8 different destination IP and port at the
same time.
10) Real COM Driver support multicomputer communication though the 9
th
(address
frame is 1, data frame is 0).
11) Support remotely searching 5143I and configuring parameters through internet,
can upgrading procedure and downloading configuration Webpage through
Ethernet port.
3. Technical Parameters
Figure
Interface:
485/422: Terminal; 232: DB9
Power Supply:
5.5mm, Inside positive outside negative, standard outlet
Size:
L x W x H =9.4cm×6.5cm×2.5cm
Communicate Interface
Ethernet:
10M/100M, 2KV surge protection
Serial
RS232/485/422×1: RXD, TXD, GND, CTS, RTS
Serial Parameters
Baud rate:
1200~115200bps
Parity bits:
None, Odd, Even, Mark, Space
Data bits:
5~9
Flow control:
RTS/CTS, NONE
Software
protocol:
ETHERNET, IP, TCP, UDP, HTTP, ARP, ICMP, DHCP, DNS
Setting method :
ZLVirCom, WEB browser, device management library
Net communication method:
Socket, Virtual serial , device management library
Work Mode
TCP server, TCP client, UDP, Real Com Driver
Power
Power:
18~36V DC, 400~600mW（can be customized 12V input）
Environment
Running temperature:
-40~85℃

ZLAN ZLAN5143I Specifications

General

Brand	ZLAN
Model	ZLAN5143I
Category	Gateway
Language	English
