Zte MU5001 User Manual

12
PC STARTUP GUIDE: THE PROCESS
1. Place SIM-Card (refer to p7 for more detail).
2. Power on the router (plug it in to ensure a continuous
stable powered connection).
3. Use your mobile phone or computer to search and
connect to the network: “Falcon 5G” - note there will be two
options to connect to, namely “Falcon 5G 2.4Ghz” and “Falcon
5G 5Ghz” . The main dierence between the two is that the
“Falcon 5G 2.4Ghz” is not as fast as “Falcon 5G 5Ghz” but it has
a longer range. Ideally connect to the “Falcon 5G 5Ghz” where
possible, for faster speeds. You can also sync the two SSID’s as
in point 4 on p11.
4. Key in the Wi key (password): “**************” (located
on the screen, refer to p11 for more detail).
5. Wait a few seconds you will be connected to the internet.

Zte MU5001 Specifications

General

Device type	Cellular network router
Product color	Black
LED indicators	Battery level, Network, Notification, Signal strength, Wi-Fi
Display diagonal	2.4 \
Market positioning	Portable
Suitable for indoor use	Yes
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi frequency	5 GHz
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
4G standard	LTE-TDD & LTE-FDD
3G standards	UMTS
Data network	5G, LTE, UMTS
SIM card type	NanoSIM
Number of SIM cards	1
USB port type	USB Type-C
Download speed	3.8 Gb/s
Processor model	SDX55
Antenna type	Internal & external
Battery capacity	4500 mAh
Power source type	Battery

Weight and Dimensions

Depth	18.5 mm
Width	133 mm
Height	73 mm
