(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Caution!
The manufacturer is not responsible for any radio or TV interference caused
by unauthorized modifications to this equipment. Such modifications could
void the user authority to operate the equipment.
2 Product Specifications
The ZXHN H167A is a VDSL2 access device that supports 1.16 Gbps
Dual-bandconcurrent 11ac Wi-Fi. It provides High Speed Internet, IPTV
services through the VDSL2/ADSL2+ uplink. Those services are delivered by
the gateway on your home network to the PCs, STBs, gaming devices and so
on via the integrated interfaces: Ethernet, Wi-Fi.
The ZXHN H167A supports Dual-Band concurrent Wi-Fi up to 300 Mbps (IEEE
802.11b/g/n 2x2 @ 2.4 GHz) and 867 Mbps(IEEE 802.11ac 2x2 @5
GHz).
Technical Specification
Dimension 210 mm (L) × 140 mm (W) × 32mm (H)
Certification CE and Wi-Fi Certification
Power adapter
Input: AC 100 V - 240 V, 50/60 Hz
Output: DC 12 V, 1 A
Environment Requirements
Operation temperature 0 °C - 40 °C (32 °F - 104 °F)
Operation humidity 5% - 95%(non-condensing)
3 Hardware Description
Front panel
Figure 3-1 shows the indicators on the front panel of the ZXHN H167A
Figure 3-1 Indicators on the Front Panel
