ZXV10ET501ProductDescription

3.2ProduceOverview

FrontPanel

ForthefrontpaneloftheZXV10ET501,seeFigure3-1.

Figure3-1FrontPaneloftheZXV10ET501

ThereisastatusindicatoronthefrontpaneloftheZXV10ET501.IftheZXV10ET501is

operatingproperly,theindicatorissolidblue.

Note:

lInshut-downstatus,pressthepowerswitchtoturntheterminalon.

lInrunningstate,Cutoffthepowersupplytotoshuttheterminaldown.

RearPanel

ForadescriptionoftheinterfacesontherearpaneloftheZXV10ET501,refertoChapter

6InterfacesandProtocols.

3-2

SJ-20161028111501-001|2017-04-10(R1.0)ZTEProprietaryandCondential
