ZWO ASI178 User Manual

ASI178 Manual
6
4. Camera technical specifications
Sensor
1 / 1.8″CMOS
Diagonal
8.95mm
Resolution
6.4 Mega Pixels 3096*2080
Pixel Size
2.4µm
Image area
7.4mm * 5mm
Max FPS at full resolution
60FPS
Shutter
Rolling shutter
Exposure Range
32µs-1000s
Read Noise
1.4~2.2e
QE peak
TBD
Full well
15k e
ADC
14 bit
Interface
USB3.0/USB2.0
Adapters
2″/ 1.25″/ M42X0.75
Protect window
AR/IR-Cut window
Dimensions
62mm
Weight
120g
Back Focus Distance
12.5mm
Supported OS
Windows, Linux & Mac OSX
Working Temperature
-5°C—45°C
Storage Temperature
-20°C—60°C
Working Relative Humidity
20%—80%
Storage Relative Humidity
20%—95%

ZWO ASI178 Specifications

General

Sensor	1 / 1.8″CMOS
ADC	14 bit
Diagonal	8.95mm
Resolution	6.4 Mega Pixels 3096*2080
Pixel Size	2.4µm
Image area	7.4mm * 5mm
Shutter	Rolling shutter
Exposure Range	32µs-1000s
Back Focus Distance	12.5mm
Max FPS at full resolution	60FPS
Read Noise	1.4~2.2e
QE peak	TBD
Full well	15k e
Interface	USB3.0/USB2.0
Adapters	2″/ 1.25″/ M42X0.75
Protect window	AR/IR-Cut window
Supported OS	Windows, Linux & Mac OSX
Working Temperature	-5°C—45°C
Storage Temperature	-20°C—60°C
Working Relative Humidity	20%—80%
Storage Relative Humidity	20%—95%

Weight and Dimensions

Dimensions	62mm
Weight	120g
