Thank You for purchasing this water heater. Properly installed and
maintained, it should give you years of trouble free service.
Abbreviations Found In This Instruction Manual:
• ANSI - American National Standards Institute
• NFPA - National Fire Protection Association
• ASME - American Society of Mechanical Engineers
• GAMA - Gas Appliance Manufacturer’s Association
• UL - Underwriters Laboratories Inc.
This gas-red water heater is design certied by Underwriters
Laboratories Inc. under American National Standard for Gas Water
Heaters ANSI Z21.10.3 (current edition).
PREPARING FOR THE INSTALLATION
1. Read the “General Safety” section, page 3 and 4 of this manual rst
and then the entire manual carefully. If you don’t follow the safety
rules, the water heater will not operate properly. It could cause
DEATH, SERIOUS BODILY INJURY AND/OR PROPERTY DAMAGE.
This manual contains instructions for the installation, operation, and
maintenance of the gas-red water heater. It also contains warnings
throughout the manual that you must read and be aware of. All warnings
and all instructions are essential to the proper operation of the water
heater and your safety. Since we cannot put everything on the rst
few pages, READ THE ENTIRE MANUAL BEFORE ATTEMPTING
TO INSTALL OR OPERATE THE WATER HEATER.
2. The installation must conform with these instructions and the local
code authority having jurisdiction. In the absence of local codes,
installations should comply with the National Fuel Gas Code (ANSI
Z223.1/NFPA 54) and the National Electrical Code (NFPA 70).
These publications are available from The National Fire Protection
Association, 1 Batterymarch Park, Quincy, MA 02269.
3. The water heater when installed must be grounded in accordance
with the local codes, or in the absence of local codes: the National
Electrical Code (NFPA 70).
4. If after reading this manual you have any questions or do not
understand any portion of the instructions, call the local gas utility
or the manufacturer whose name appears on the rating plate.
5. Carefully plan the place where you are going to put the water
heater. Correct combustion, vent action, and vent pipe installation
are very important in preventing death from possible carbon
monoxide poisoning and res, see Figures 1 and 2.
Examine the location to ensure the water heater complies with
the “Locating the New Water Heater” section in this manual.
6. For California installation this water heater must be braced,
anchored, or strapped to avoid falling or moving during an
earthquake. See instructions for correct installation procedures.
Instructions may be obtained from California Ofce of the State
Architect, 400 P Street, Sacramento, CA 95814.
7. Massachusetts Code requires this water heater to be installed in
accordance with Massachusetts 248-CMR 2.00: State Plumbing
Code and 248-CMR 5.00. For more information see next page.
8. Complies with SCAQMD rule #1146 and districts having equivalent
NOx requirements.
INTRODUCTION
TABLE OF CONTENTS
SAFE INSTALLATION, USE AND SERVICE.................................. 2
GENERAL SAFETY.....................................................................3-4
TABLE OF CONTENTS .................................................................. 5
INTRODUCTION ............................................................................ 5
Preparing for the Installation ................................................... 5
INSTALLATION REQUIREMENTS FOR THE
COMMONWEALTH OF MASSACHUSETTS ................................. 6
TYPICAL INSTALLATION ............................................................ 7-8
LOCATING THE NEW WATER HEATER .................................. 9-11
Facts to Consider About Location ...................................... 9-10
Insulation Blankets ................................................................ 10
Combustion Air and Ventilation for Appliances
Located in Unconned Spaces ............................................. 10
Combustion Air and Ventilation for Appliances
Located in Conned Spaces ............................................ 10-11
INSTALLING THE WATER HEATER ....................................... 12-22
Chemical Vapor Corrosion .................................................... 12
Water Piping ....................................................................12-13
Temperature-Pressure Relief Valve ...................................... 13
Gas Piping ............................................................................ 14
Sediment Traps ..................................................................... 15
Filling the Water Heater ........................................................ 15
Venting .................................................................................. 15
Vent Pipe Termination ...................................................... 15-16
Planning the Vent System ................................................ 16-17
Condensate........................................................................... 17
Blower Assembly Installation ........................................... 17-18
Installation of Vent System...............................................18-21
Vent Pipe Preparation ......................................................21-22
LIGHTING & OPERATING LABEL ...............................................23
TEMPERATURE REGULATION .................................................. 24
FOR YOUR INFORMATION ......................................................... 25
Start Up Conditions
Smoke/Odor ..................................................................25
Thermal Expansion ....................................................... 25
Strange Sounds ............................................................25
Operational Conditions ......................................................... 25
Smelly Water ................................................................. 25
“Air” in Hot Water Faucets ............................................. 25
High Temperature Shut Off System ............................... 25
PERIODIC MAINTENANCE ....................................................26-28
Venting System Inspection.................................................... 26
Burner Operation and Inspection .......................................... 26
Burner Cleaning .................................................................... 26
Housekeeping ..................................................................26-27
Anode Rod Inspection...........................................................27
Temperature-Pressure Relief Valve Operation .....................27
Draining.................................................................................27
Service .................................................................................. 28
LEAKAGE CHECKPOINTS .......................................................... 28
REPAIR PARTS ............................................................................ 29
TROUBLESHOOTING ............................................................30-32
WARRANTY ................................................................................. 35
