ABB ACH550-01 User Manual

396 Technical data
ACH550-01 User's Manual
IEC ratings, 380…480 V drives
Type Valid up to 40 °C
Frame
size
ACH550-01-
I
2N
A
P
N
kW
Max.
current I
MAX
Three-phase supply voltage, 380…480 V
02A4-4 2.4 0.75 3.1 R1
03A3-4 3.3 1.1 4.3 R1
04A1-4 4.1 1.5 5.9 R1
05A4-4 5.4 2.2 7.4 R1
06A9-4 6.9 3.0 9.7 R1
08A8-4 8.8 4.0 12.4 R1
012A-4 11.9 5.5 15.8 R1
015A-4 15.4 7.5 21.4 R2
023A-4 23 11 27.7 R2
031A-4 31 15 41 R3
038A-4 38 18.5 56 R3
045A-4 45 22 68 R3
059A-4 59 30 79 R4
072A-4 72 37 106 R4
087A-4 87 45 139 R4
125A-4 125 55 173 R5
157A-4 157 75 223 R6
180A-4 180 90 281 R6
195A-4 205 110 324 R6
246A-4 246 132 346 R6
290A-4 290 160 441 R6
00467918.xls C
I
MAX
: Maximum output current allowed for 2 seconds every minute
