Installing the drive 37
ACH550-01 User's Manual
Installing the drive
What this chapter contains
This chapter contains the mechanical and electrical installation
procedure of the drive.
WARNING! Before installing the ACH550, ensure the input
power supply to the drive is off.
For flange mounting (mounting the drive in a cooling air duct),
see the appropriate Flange Mounting Instructions:
Note: The ACH550 should only be mounted where all of the
requirements defined in chapter Preparing for installation are
met and the checklist has been completed.
Frame
size
IP21 / UL type 1 IP54 / UL type 12
Kit
Code (English)
Kit
Code (English)
R1 FMK-A-R1 100000982 FMK-B-R1 100000990
R2 FMK-A-R2 100000984 FMK-B-R2 100000992
R3 FMK-A-R3 100000986 FMK-B-R3 100000994
R4 FMK-A-R4 100000988 FMK-B-R4 100000996
