CHAPTER 10 – PREVENTIVE AND CORRECTIVE MAINTENANCE 156
10.2 Identifying electrical
equipment
Electrical identification is done in accordance with IEC 81346-1.
10.2.1 Device designation
To facilitate the identification in wiring diagrams
and parts lists, all devices are labeled in accor-
dance with IEC 81346-1.
10.2.2 Identifying cables and wires
Cables and wires in the drive are equipped with
marker sleeves which carry the same identification
number as in the wiring diagrams.
10.2.3 Understanding the wiring diagrams
For information on item designation and
cross-reference conventions, see Appen-
dix D – Wiring diagrams.
10-1 Device identification
