Mechanical installation
25
Cable gland kit part list
Tightening torques
R1 Cable Gland Kit,
3AUA0000045483
R3 Cable Gland Kit,
3AUA0000045484
Pcs Part Pcs Part
5 M25 cable gland 2 M32 cable gland
3 M25 back nut 2 M32 back nut
1 M12 cable gland 3 M25 cable gland
1 M25 back nut
1 M12 cable gland
Tightening torques Tightening torques, optional parts
Part N
·mPart N·m
Panel cover screws 2.0 Cable gland, size M12 3.0
Cover screws 2.0 Cable gland, size M25 8.0
Cable gland screws 2.0 Cable gland, size M32 10.0
EMC and VAR screws 0.5 Pressure compensation valve 0.8
Fan screws 1.2 Cable hole plugs 1.5
R1 input switch terminal screws 0.8
R3 input switch terminal screws 2.0
