26.4.1 Process Supply Voltage

CAUTION!

The process supply voltage must be included in the earthing concept (e. g.

earthing of the minus pole).

26.4.2 Inputs/Outputs

Fig. 37: Example for connection input Ix

Examples

DX581-S

Connection > Inputs/Outputs

2019/11/15 3ADR024117M02xx, 11, en_US 207
