Specification of Variants and Options
Product Specification IRB 4400 M98A/BaseWare OS 3.2 57
Figure 36 Mounting plate for mounting of equipment (dimensions in mm).
CABINET TYPE
121 Standard, i.e. without Castor wheels.
122 Cabinet on Castor wheels.
OPERATOR’S PANEL
The operator’s panel and teach pendant holder can be installed in different ways.
181 Standard, i.e. on the front of the cabinet.
182 External, i.e. in a separate operator’s unit.
All necessary cabling, including flange, connectors, sealing strips, screws, etc., is
supplied. External enclosure is not supplied. (See Figure 37).
183 External, mounted in a box. (See Figure 38)
Shaded area 40x40
(four corners) not available
705
730
for mounting
