2.5 Electrical Interconnection
The Series 10D1476S K-MAG magnetic flowmeter is furnished with a remotely mounted signal
converter. Interconnection wiring is done in the customer connection box shown in Figure 2-13. For
additional information and wiring details, refer to interconnection diagrams provided in the instruction
manual supplied with the signal converter.
WARNING
Equipment powered by ac line voltage constitutes a potential electric shock
hazard to the user. Make certain that the system power input leads are
disconnected from the operating branch circuit before attempting electrical
interconnections.
FIGURE 2-13. 10D1476S REMOTE CUSTOMER CONNECTION BOX
When making wiring interconnections between the flowmeter and the remote signal converter, the
grounding procedures given in Section 2.4 must be followed.
10D1476 K-MAG MAGNETIC FLOWMETER INSTRUCTION MANUAL
2-18
