6.3 Mounting
Pos: 85. 1 /Di nA4 - Anlei t ung en Onl ine/I nhal t/K NX /DoorE ntry/ 832 20-A P-xxx / Monta ge - Mo dule/ Mon tage - Mon tage dos e -- 83 220 -AP -xxx @ 19\ mod _132 325040 684 8_1 5.doc x @ 1 110 98 @ @ 1
Recommended installation height
Dismantling
Pull the clamp on the bottom of the device and then open the housing of the panel.
Installation dimensions for slotted screw holes
