• Use only suitable tools and measuring devices.
• Check the type supply network (TN system, IT system, TT system)
to secure the following power supply conditions (classic connection
to ground, protective earthing, necessary additional measures,
etc.).
Pos: 82 /DinA 4 - Anleitungen Online/Inhalt/KN X/DoorEntry/Mo ntage/Mont agehinweise - Allg emein @ 1 9\mod_13105 63670478_15.d ocx @ 107743 @ 2 @ 1
6.2 General installation instructions
• Terminate all branches of the wiring system via a connected bus device (e.g.,
indoor station, outdoor station, system device).
• Do not install the system controller directly next to the bell transformer and other
power supplies (to avoid interference).
• Do not install the wires of the system bus together with 100-240 V wires.
• Do not use common cables for the connecting wires of the door openers and wires
of the system bus.
• Avoid bridges between different cable types.
• Use only two wires for the system bus in a four-core or multi-core cable.
• When looping, never install the incoming and outgoing bus inside the same cable.
• Never install the internal and external bus inside the same cable.
