3GZF500730-70 rev. C RU-EN 01-2016 | ABB Motors and Generators EN – 43
NOTE!
An increase in the ambient temperature raises the
temperature of the bearings correspondingly. The
interval values should be halved for a 15 °C increase
in bearing temperature and may be doubled for a
15 °C decrease in bearing temperature.
Higher speed operation, e.g. in frequency converter
applications, or lower speed with heavy load will require
shorter lubrication intervals.
WARNING
The maximum operating temperature of the grease
and bearings, +110°C, must not be exceeded.
The designed maximum speed of the motor must
not be exceeded.
Ball bearings
Frame
size
Amountof grease
DE-bearing [g]
Amount of grease
NDE-bearing [g]
3600
r/min
3000
r/min
1800
r/min
1500
r/min
1000
r/min
500-900
r/min
Lubrication intervals in duty hours
160 13 13 7 100 8 900 14 300 16 300 20 500 21 600
180 15 15 6 100 7 800 13 100 15 100 19 400 20 500
200 20 15 4 300 5 900 11 000 13 000 17 300 18 400
225 23 20 3 600 5 100 10 100 12 000 16 400 17 500
250 30 23 2 400 3 700 8 500 10 400 14 700 15 800
280 35 35 1 900 3 200 – – – –
280 40 40 – – 7 800 9 600 13 900 15 000
315 35 35 1 900 3 200 – – – –
315 55 40 – – 5 900 7 600 11 800 12 900
355 35 35 1 900 3 200 – – – –
355 70 40 – – 4 000 5 600 9 600 10 700
400 40 40 1 500 2 700 – – – –
400 85 55 – – 3 200 4 700 8 600 9 700
450 40 40 1 500 2 700 – – – –
450 95 70 – – 2 500 3 900 7 700 8 700
Roller bearings
Frame
size
Amountof grease
DE-bearing [g]
Amount of grease
NDE-bearing [g]
3600
r/min
3000
r/min
1800
r/min
1500
r/min
1000
r/min
500-900
r/min
Lubrication intervals in duty hours
160 13 13 3 600 4 500 7 200 8 100 10 300 10 800
180 15 15 3 000 3 900 6 600 7 500 9 700 10 200
200 20 15 2 100 3 000 5 500 6 500 8 600 9 200
225 23 20 1 800 1 600 5 100 6 000 8 200 8 700
250 30 23 1 200 1 900 4 200 5 200 7 300 7 900
280 35 35 900 1 600 – – – –
280 40 40 – – 4 000 5 300 7 000 8 500
315 35 35 900 1 600 – – – –
315 55 40 – – 2 900 3 800 5 900 6 500
355 35 35 900 1 600 – – – –
355 70 40 – – 2 000 2 800 4 800 5 400
400 40 40 – 1300 – – – –
400 85 55 – – 1 600 2 400 4 300 4 800
450 40 40 – 1 300 – – – –
450 95 70 – – 1 300 2 000 3 800 4 400
