Section 3 Location of interface ports and LED‘s
3BSE080633 17
LED Status Description
ON OFF Unit has no power
GREEN All OK, no alarm condition
RED
Alarm condition, or until unit has started up. (Alarm
conditions are congurable,see, NEOS User Manual)
BLINK
Location indicator “Here I am”.
Activated when connected to IPCong Tool, or upon
request from Web or CLI
DC1 OFF Unit has no power
GREEN Power OK on DC1
RED Power failure on +DC1
DC2 OFF Unit has no power
GREEN Power OK on DC2
RED Power failure on +DC2
FRNT OFF FRNT disabled
GREEN FRNT OK
RED FRNT Error
BLINK Unit congured as FRNT Focal Point
RSTP OFF RSTP disabled
GREEN RSTP enabled
BLINK Unit elected as RSTP/STP root switch
USR1 OFF Congurable, see NEOS User Manual
GREEN
RED
OFF No Link
GREEN Link established
GREEN FLASH Data trafc indication
YELLOW
Port alarm and no link. Or if RFNT or RSTP mode, port
is blocked
1 to 10
