ABB PVI-3.0-TL-OUTD User Manual

- 17 -
000400BG
2 - Characteristics
Table: Technical Data PVI-3.0-TL-OUTD PVI-3.6-TL-OUTD PVI-4.2-TL-OUTD
Operating performance
Maximum Efciency (ηmax) 96.8%
Weighted Efciency (EURO/CEC) 96% / -
Power Supply Threshold 10.0 W
Night-Time Consumption < 1.0 W
Communication
Wired Local Monitoring (opt.) PVI-USB-RS232_485 (opt.)
Remote Monitoring (opt.)
VSN300 Wi Logger Card (opt.), PVI-AEC-EVO (opt.),
VSN700 Data Logger (opt.)
Wireless Local Monitoring (opt.) VSN300 Wi Logger Card (opt.)
User Interface LCD Display with 16 characters x 2 line
Environmental
Ambient temperature
-25...+60°C
-13...140°F
with derating above
50°C / 122°F
-25...+60°C
-13...140°F
with derating above
55°C / 131°F
-25...+60°C
-13...140°F
with derating above
50°C / 122°F
Storage temperature -40...80°C (-40...+176°F)
Relative Humidity 0...100% condensing
Typical noise emission pressure 50 db(A) @ 1 m
Maximum operating altitude 2000 m / 6560 ft
Environmental pollution classication
for external environment
3
Environmental Category External
Physical
Environmental Protection Rating IP 65
Cooling System Natural
Overvoltage rating as per IEC 62109-1 II (DC input) III (AC output)
Dimensions (H x W x D) 618mm x 325mm x 222mm / 24.3” x 12.8” x 8.7”
Weight 17.5 kg / 38.6 lb
Assembly System Wall bracket
Safety
Safety class I
Insulation level Without transformer (TL)
Marking CE (50Hz only)
Safety and EMC Standards
EN62109-1,
N62109-2,
AS/NZS3100,
AS/NZS 60950,
EN61000-6-1,
EN61000-6-3,
N61000-3-2,
EN61000-3-3
EN62109-1,
EN62109-2,
AS/NZS3100,
AS/NZS 60950,
EN61000-6-1,
EN61000-6-3,
EN61000-3-11,
EN61000-3-12
EN62109-1,
EN62109-2,
AS/NZS3100,
AS/NZS 60950,
EN61000-6-1,
EN61000-6-3,
EN61000-3-11,
EN61000-3-12
Grid Standard
CEI 0-21, VDE 0126-1-1,
VDE-AR-N 4105, G83/2,
EN 50438 (not for all
national appendices),
RD1699, AS 4777,
C10/11, IEC 61727,
ABNT NBR 16149,
CLC/FprTS 50549
CEI 0-21, VDE 0126-1-1,
VDE-AR-N 4105, G83/2,
G59/3, EN 50438 (not for
all national appendices),
RD1699, AS 4777,
C10/11, IEC 61727,
ABNT NBR 16149,
CLC/FprTS 50549,
PEA, MEA
CEI 0-21, VDE 0126-1-1,
VDE-AR-N 4105, G59/3,
EN 50438 (not for all
national appendices),
RD1699, AS 4777,
C10/11, IEC 61727,
ABNT NBR 16149,
CLC/FprTS 50549
1. The output voltage range may vary according to the grid standard of the country of installation
2. For G83/2 setting, maximum output current limited to 16 A up to a maximum output power of 3.68 kW
3. The output frequency range may vary according to the grid standard of the country of installation
4. Refer to the document “String inverter – Product Manual appendix” available at www.abb.com/solarinverters to know
the brand and the model of the quick t connector
Note. Features not specically mentioned in this data sheet are not included in the product
