Network configuration
42
Method Description Note
DIP switch (S1) By default, the IP address is defined by
software (see chapter Communication).
Setting any DIP actuator to ON enables
hardware selection. DIP actuators 1 to 8
define the last octet (1 to 254) of the IP
address in binary. Actuator 8 represents the
least significant bit.
Only read at
start-up.
Only for intranet
use.
IP address: 192.168.0.xxx
Subnet mask: 255.255.255.0
Gateway: 0.0.0.0
where xxx stands for a value between 1 and
254 and is selected by DIP switch S1.
Example DIP settings:
Intranet IP
address
S1 actuator
positions
(Selected by
software)
OFF oooooooo
ON
12345678
192.168.0.1 OFF ooooooo
ON o
12345678
192.168.0.2 OFF oooooo o
ON o
12345678
• • • • • •
192.168.0.255 OFF
ON oooooooo
12345678
