6 TEIP11, TEIP11-PS I/P SIGNAL CONVERTER | OI/TEIP11/TEIP11-PS-EN REV. M
… 2 Use in potentially explosive atmospheres
… Flameproof (enclosure), ATEX ‘Ex d’
Temperature classes for the following versions:
TEIP11 Doc. 901068-SMD and TEIP11-PS Doc. 901068-SMD and
TEIP11-PS Doc. 901069-SMD
Temperature class Input current Ambient temperature
range
T4 120 mA –55 to 60 °C
T4 100 mA –55 to 85 °C
T6 60 mA –55 to 40 °C
TEIP11 Doc. 901068 and TEIP11-PS Doc. 901068 and TEIP11-PS
Doc. 901069
Temperature class Input current Ambient temperature
range
T6 50 mA –55 to 60 °C
T6 60 mA –55 to 55 °C
T5 60 mA –55 to 70 °C
T4 60 mA –55 to 85 °C
T5 100 mA –55 to 55 °C
T4 100 mA –55 to 85 °C
T5 120 mA –55 to 45 °C
T4 120 mA –55 to 80 °C
T4 150 mA –55 to 70 °C
Ex limit values
L
i
U
i
P
i
50 mA 42.5 V 2.125 W
60 mA 38.8 V 2.328 W
100 mA 30 V 3.0 W
120 mA 28 V 3.36 W
150 mA 25.5 V 3.825 W
Special conditions
The I/P signal converter TEIP11-PS Doc. 901068 or TEIP11-PS Doc.
901069 must be set up outdoors as a pneumatic power supply
when used with combustible gases.
The supplied gas must be kept sufficiently free of air and oxygen
to prevent a potentially explosive atmosphere from forming.
The gas must always be routed to the outside.
FM / CSA
Intrinsically safe FM
FM ‘intrinsically safe’ (not for metal field housing units)
I.S.: CL I/Div 1/Grp A B C D
FM ‘intrinsically safe’ (only for metal field housing units)
I.S.: CL I-II-II/Div 1/Grp A B C D E F G
S.: CL II/Div 2/Grp G
S.: CL III/Div 2
Non-incendive FM
N.I.: CL I/Div 2/Grp A B C D (not for metal field housing units)
N.I.: CL I/Div 2/Grp A B C (only for metal field housing units)
Intrinsically safe CSA
CSA ‘intrinsically safe’ (not for metal field housing units)
I.S.: CL I/Div 1/Grp A B C D
CL I / Div 2 / Grp A B C D
CSA ‘intrinsically safe’ (only for metal field housing units)
I.S.: CL I/Div 1/Grp A B C D
CL II / Div 1 / Grp E F G
CL III
CL I / Div 2 / Grp A B C D
CL II / Div 2 / Grp E F G
Non-incendive CSA
FM ‘explosion proof’ (only for metal field housing units)
X.P.: CL I/Div 1/Grp B C D
D.I.P.: CL II III/Div 2/Grp E F G
CSA ‘explosion proof’ (only for metal field housing units)
X.P.: CL I/Div 1/Grp B C D
