Accuphase E-212 User Manual

2-14-10 SHIN-ISHIKAWA, AOBA-KU, YOKOHAMA, JAPAN
2001-8 861-3122-00
Printed in Japan
SPECIFICATIONS
[Guaranteed specifications are measured according to EIA standard RS-490.]
(both channel driven, 20 - 20,000Hz)
115 watts per channel into 4 ohms
105 watts per channel into 6 ohms
90 watts per channel into 8 ohms
(both channel driven, 20 - 20,000Hz)
0.04% with 4 to 16 ohms load
0.01%
HIGHLEVEL INPUT
20-20,000Hz +0, -0.2dB (at rated continuous average output)
100 (with 8-ohm load ,50Hz)
Sensitivity
Input for rated output for 1watt output (EIA) Input Impedance
HIGH LEVEL 213mV 22.5mV 20k
Ω
BALANCED 213mV 22.5mV 40k
Ω
HIGH LEVEL INPUT
→
OUTPUT : 42dB
(UNBALANCED/BALANCED)
Turnover frequency and adjustment range
BASS : 300Hz
±
10dB (50Hz)
TREBLE 3kHz
±
10dB (20kHz)
+6dB (200Hz) (Volume control setting -30dB)
-20dB
Input shorted,IHF-A weighting
Input S/N ratio at rated input S/N ratio (EIA)
HIGH LEVEL 110dB 81dB
BALANCED 98dB 81dB
Logarithmic compression,peak reading meters with a dB
scale calibrated for an 8-ohm load
4-16 ohms
Suitable impedance : 8-100 ohms
120V /230V (Voltage as indicated on rear panel)
AC,50/60Hz
30 watts idle
220 watts in accordance with IEC-65
Width 475 mm (18-11/16")
Height 150mm (5-7/8")
Depth 422mm (16-5/8")
18.9 kg (41.6lbs) net
23.0 kg (50.7lbs) in shipping carton
Remote control principle :Infrared pulse
Power supply :3V DC(IEC R6 batteriesx2)
Dimensions : 45(W)x136(H)x18(D)mm
Weight : 85g(including batteries)
(
両チャンネル同時動作
20
～
20,000Hz
間
)
115 W/ch 4
Ω負荷
105 W/ch 6
Ω負荷
90 W/ch 8
Ω負荷
(
両チャンネル同時動作
20
～
20,000Hz
間
)
0.04% 4
～
16
Ω
0.01%
HIGH LEVEL INPUT
定格連続平均出力時
:20
～
20,000Hz 0 -0.2dB
100 (8
Ω負荷
50Hz)
入力感度
入力端子 定格出力時
EIA(1W
出力
)
入力ｲﾝﾋﾟｰﾀﾞﾝｽ
HIGH LEVEL 213mV 22.5mV 20k
Ω
BALANCED 213mV 22.5mV 40k
Ω
HIGH LEVEL INPUT
→
OUTPUT : 42dB
: 300Hz
±
10dB (50Hz)
:3kHz
±
10dB (20kHz)
+6dB (200Hz) : VOLUME -30dB
にて
-20 dB
入力ショート
(A-
補正
)
入力端子 定格出力時
S/N
入力換算雑音
EIA S/N
HIGH LEVEL 110dB -129dBV 81dB
BALANCED 92dB -111dBV 81dB
対数圧縮型ピークレベル表示
dB
目盛及び
8
Ω負荷の出力直読
4
～
16
Ω
適合インピーダンス
8
～
100
Ω
AC100V 50 /60Hz
30W
無入力時
220W
電気用品取締法
336W 8
Ω負荷定格出力時
法
幅
475mm
×高さ
150mm
×奥行
422mm
18.9kg
ﾘﾓｺﾝ方式
:
赤外線ﾊﾟﾙｽ方式
電源
:DC3V
・乾電池 単
3
型
2
個使用
最大外形寸法
:45
㎜ｘ
136
㎜ｘ
18
㎜
質量
: 85g(
電池含む
)
