Appendix A Specifications
82
English
I/O ports
• One type II PC Card slot (PCMCIA and CardBus)
• One IEEE 1394 port
• One RJ-11 modem jack (V.92, 56K)
• One RJ-45 network jack (GigabitLAN 100/1000)
• One DC-in jack
• One parallel port
• One S-video port (NTSC/PAL)
• One external monitor port
• One microphone-/line-in jack
• One headphone-/speaker-/line out jack
• Infrared (FIR) port
• Three USB 2.0 ports
• 4 in 1 Card Reader (MS/MMC/SD/SM)
Weight and dimensions
• 15.4”-display model:
- 3.0 kg (6.6 lbs)
- 360(W) x 273(D) x 28 ~ 33.49(H) mm
- (14.2” x 10.7” x 1.1”~ 1.32”)
Environment
• Temperature:
- Operating: 5°C ~ 35°C
- Non-operating: -20°C ~ 65°C
• Humidity (non-condensing):
- Operating: 20% ~ 80% RH
- Non-operating: 20% ~ 80% RH
Operating system
• Microsoft Windows XP
Power
• 8-cell Li-Ion battery pack
• 65W AC adapter
