Main Board Layout
Label Part number Description
CN405 88G 35315F H D-SUB 15PIN
CN101 33G801724B H PIN HEADER 24P 2.0mm
U401 56G 562100 TSUM16AK
X401 93G 22 53 CRYSTAL 14.318MHzHC-49U
