120 Chapter 3
3. Replace the adhesive strip on the left hinge.
4. Replace the two securing screws on the left hinge as shown.
5. Reconnect the Microphone cable to the Mainboard as shown.
Step Size Quantity Screw Type
LCD Module M2.5*5 2
