Chapter 3 125
Replacing the Switch Board
1. Connect and lock the FFC.
2. Turn the switch board over and place into the upper cover.
3. Replace the two (2) screws.
Step Size Quantity Screw Type
Switch Board
Assembly
T2.5*2 2
