General Keys
Item Description
Power button Press to turn your TV on/off.
DISPLAY Displays the channel number and input source on the upper right-
hand corner of the screen.
MUTE Press once to mute the sound; press again to restore.
TV Press to toggle select TV mode.
AV Press to toggle between AV1, AV2, AV3 and AV4.
Component Press to toggle between Component1, Component2 and Component3.
PC Press to toggle sources between VGA and DVI
Number keys Number keys from 0-9.
ENTER Press to confirm channel selections by the number keys.
RECALL Press to return to the previous channel.
CC Press to select close caption and text service between CC1, CC2,
CC3,CC4, Text1, Text2, Text3. Text4.
MENU Press to open Menu or leave Menu.
4-way scroll key/OK When the OSD is on: Navigate up, down, left and right in the OSD
menu / press OK to confirm.
MTS Press to switch the sound system between stereo, main, and SAP. In-
formation is displayed in the top right-hand corner.
e Acer empowering key for Favorite Channel, Scenario Mode. See
page 18.
CH (up/down) Press to sequentially select the TV channel.
VOL (up/down) Press to increase or decrease the volume.
PIP/PBP/POP Switch between PIP/PBP/POP modes. See page 20.
SWAP When in PIP/PBP mode: Toggle primary and sub- screens.
ACTIVE When in POP mode: Toggle the active screen.
POSITION When in PIP mode: Change position of sub- screen
SIZE/MODE When in PIP mode: Select sub- screen size (25%, 37.5%, 50%)
When in POP mode: Switch POP mode between 1+5 and 1+12
SLEEP Set a time period after which the TV will switch itself to standby.
Press repeatedly to select the number of minutes.
WIDE
Press to toggle scaling mode between 4:3, 16:9, Panorama and Letterbox
ZOOM Press to switch image between
Normal Zoom1 (1.85:1) Zoom2 (2.35:1)
SRS Press to select WOW, TruBass, 3D Stereo, Off modes sequentially. SRS
is a technology to enhance 3D sound, bass performance and to pro-
duce a wider sound field.
4:3 16:9 Panorama Letterbox

Acer AT3201W Specifications

Display

resolution	1366 x 768 pixels
brightness	500 nits
contrast ratio	800:1
display colors	16.7 M
viewing angle	H:170 ; V:170
response time	12 ms (gray to gray)

Power

input voltage	100V to 240 V-AC
max power consumption	210 W
power saving	5 W

Ports & interfaces

audio system AV1	RCA for CVBS, S-Video, Audio R/L
audio system AV2	RCA for CVBS, S-Video, Audio R/L
component1	RCA for YPbPr/YCbCr, Audio R/L
component2	RCA for YPbPr/YCbCr, Audio R/L
component3	RCA for YPbPr/CbCr, Audio R/L
audio system AV3	RCA for CVBS, Audio R/L
audio system AV4	S-Video, Audio R/L
PC D-sub	Yes
DVI-D(HDCP)	Yes
PC audio-in	Yes
audio-out	Yes
headphones	Yes

Audio

3D surround	Yes
speakers	10 W + 10 W
SRS WOW	25

Weight and Dimensions

dimensions	1018 x 616 x 210 mm
swivel angle	40 degrees
weight	20.7 kg
