Acer G245H User Manual

EN-10
24-Pin Color Display Signal Cable*
PINMeaningPINMeaning
1.TMDS Data2-13.NC
2.TMDS Data2+14.+5V Power
3.TMDS Data 2/4 Shield15.Logic Ground
4.NC16.Hot Plug Detect
5.NC17.TMDS Data0-
6.DDC Clock18.TMDS Data0+
7.DDC Data19.TMDS Data 0/5 Shield
8.NC20.NC
9.TMDS Data1-21.NC
10.TMDS Data1+22.TMDS Clock Shield
11.TMDS Data 1/3 Shield23.TMDS Clock+
12.NC24.DDC TMDS Clock-
19-Pin color display signal cable*
PINMeaningPINMeaning
1.TMDS Data2+10.TMDS Clock+
2.TMDS Data2 Shield11.TMDS Clock Shield
3.TMDS Data2–12.TMDS Clock–
4.TMDS Data1+13.CEC
5.TMDS Data1 Shield14.
Reserved (N.C. on
device)
6.TMDS Data1–15.SCL
7.TMDS Data0+16.SDA
8.TMDS Data0 Shield17.DDC/CEC Ground
9.TMDS Data0–18.+5V Power
19.Hot Plug Detect
* only for certain models

Acer G245H Specifications

General

Pixel pitch	0.276 x 0.276 mm
Aspect ratio	16:9
Response time	2 ms
Display diagonal	24 \
Vertical scan range	55 - 75 Hz
Viewable size, vertical	299 mm
Contrast ratio (typical)	-
Viewable size, horizontal	531 mm
Viewing angle, horizontal	176 °
Display brightness (typical)	300 cd/m²
HDCP	Yes
DVI-I ports quantity	0
Certification	CE, TÜV GS, ISO 13406-2
Product color	Black
Tilt angle range	-5 - 15 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (off)	0.8 W
Power consumption (standby)	1.2 W
Power consumption (typical)	30.5 W

Weight and Dimensions

Depth (without stand)	417.8 mm
Width (without stand)	574.8 mm
Height (without stand)	194.4 mm
Weight (without stand)	5100 g
