Acer V173 Service Guide

- 13 -
Note 4) After stabilizing and leaving the panel alone at a given temperature for 30 min, the measurement
should be executed .Measurement should be executed n a stable, windless ,and dark room.30 min
after lighting the back-light. This should be measured in the center of screen. Dual lamp
current :13.0mA(6.5mA x2)(Refer to the note(1) in the page 14 for more information ).
Environment condition :Ta=25±2°C
Optical characteristics measurement setup

Acer V173 Specifications

General

Screen Size	17 inches
Resolution	1280 x 1024
Aspect Ratio	5:4
Panel Type	TN
Brightness	250 cd/m²
Contrast Ratio	700:1
Response Time	5 ms
Viewing Angle (H/V)	160°/160°
Inputs	VGA
Weight	3.5 kg
