Acer V223HQ User Manual

English
Attaching/removing the base
Screen position adjustment
Attaching:
Align the release button on the
bottom of the monitor with the
corresponding slots on the bottom of
the base.
Removing:
Press the release button as
indicated, then pull in the direction
of the arrow to remove the base.
To optimize the viewing position, you can adjust the monitor tilt by using
both of your hands to hold the edges of the monitor as shown below.
The monitor can be adjusted to 15 degrees up or 5 degrees down.

Acer V223HQ Specifications

General

Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display diagonal	21.5 \
Vertical scan range	55 - 75 Hz
Horizontal scan range	30 - 80 kHz
Viewable size, vertical	268 mm
Contrast ratio (typical)	-
Viewable size, horizontal	476.6 mm
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Power management	ENERGY STAR
Display viewable area (HxV)	476.6 x 268 mm
Mean time between failures (MTBF)	50000 h
Certification	TCO03
Product color	Black
Cable lock slot	Yes
Tilt angle range	-5 - 15 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (off)	0.67 W
Power consumption (standby)	0.79 W
Power consumption (typical)	30 W

Weight and Dimensions

Depth (without stand)	195 mm
Width (without stand)	371.52 mm
Height (without stand)	507.84 mm
Weight (without stand)	4500 g
