Acer V226HQL User Manual

2
The display support is aligned with the corresponding slot of the base,rmly installed on the base;
Align the rotating shaft above the support with the corresponding slot below the monitor and install
it rmly on the monitor.
Installing monitor
1. Remove the monitor bracket and base from the packaging and place it on a stable and level
workspace.
2.
(As shown below)
Power saving
The monitor will be switched to "power saving" mode by the control signal from the display
controller, as indicated by the orange-colored power LED.
Model LED light
On Green
Power saving Orange
The power saving mode will be kept until a control signal has been detected or the keyboard or
mouse is activated. The recovery time from "power saving" mode back to "on" is around 3 seconds.
Display Data Channel (DDC)
To make installation easier, so long as your system supports the DDC protocol, the monitor is able
to plug-and-play. The DDC is a communication protocol through which the monitor automatically
informs the host system about its capabilities; for example, supported resolutions and corresponding
timing. The monitor supports the DDC2B standard.
3. Support wall hanging function, VESA100*100mm, M4*10 screws.

Acer V226HQL Specifications

General

Style	Flat
Color	Black
Screen Type	-
Stand Type	Simple
Wall Mount	VESA 100 x 100 mm
Tilt	-5° to 25°
Sound	-
Features	Picture-In-Picture
OS Compatibility	Mac
Interface Connectors	RF In
Operation Conditions	humidity 10% to 80% (non-condensing)
Tiltable	yes
Touch Screen	no
Screen Size	54.6 cm (21.5"")
Panel Type	TN LCD
Aspect Ratio	16:9
Resolution	1920 x 1080
Refresh Rate	60 Hz
Viewing Angle	-
Response Time	5 ms
Brightness	450 cd/m²
Contrast Ratio	3000:1
Pixel Pitch	-
Type	-
Power Supply	100-240V
Power Consumption	26 W (typ)
Depth with Stand	8.1 in
Height with Stand	15.4 in
Width with Stand	20.0 in
Net Weight with Stand	8.07 lb
Depth without Stand	2.0 in
Height without Stand	12.0 in
Width without Stand	20.0 in
Net Weight without Stand	7.14 lb
Built-In Speakers	no
