Acer X34GS User Manual

- 2 -
Contents
Table of Contents
Important Safety Notice------------------------------------------------------------------------------------- 03
01. Product Specification---------------------------------------------------------------------------------- 04
02. OSD Menu------------------------------------------------------------------------------------------------ 36
03. Exploded Di a gram -------------------------------------------------------------------------------------- 46
04. Wiring connectivity diagram--------------------------------------------------------------------------- 47
05. Mechanical Instruction---------------------------------------------------------------------------------- 47
06. Assembly and Disassembly Procedures----------------------------------------------------------- 48
07.
Trouble shooting--------------------------------------------------------------------------------------- 55
08. Firmware Upgrade Procedure ------------------------------------------------------------------------ 58
09. Writing EDID Procedure------------------------------------------------------------------------------- 61
10. SN Writing Process -----------------------------------------------------------------------------------
64
11. FRU (Field Replaceable Unit) List--------------------------------------------------------------------
66
12. Timing table ----------------------------------------------------------------------------------------------- 69

Acer X34GS Specifications

General

Screen Size	34 inches
Resolution	3440 x 1440
Panel Type	IPS
Refresh Rate	180Hz
Aspect Ratio	21:9
Contrast Ratio	1000:1
HDR	HDR400
Curvature	1900R
Color Gamut	98% DCI-P3
VESA Mount	100 x 100 mm
Brightness	400 cd/m²
Adaptive Sync	G-Sync Compatible
Connectivity	2x HDMI 2.0, 1x DisplayPort 1.4, 4x USB 3.0
Stand Adjustments	Height, Tilt
