Acer XB252Q User Manual

EN-8
CONNECTOR PIN ASSIGNMENT
19-Pin Color Display Signal Cable*
* only for certain models
20-Pin Color Display Signal Cable
PIN Meaning PIN Meaning
1. TMDS Data2+ 10. TMDS Clock+
2. TMDS Data2 Shield 11. TMDS Clock Shield
3. TMDS Data2- 12. TMDS Clock-
4. TMDS Data1+ 13. CEC
5. TMDS Data1 Shield 14. Reserved (N.C. on device)
6. TMDS Data1- 15. SCL
7. TMDS Data0+ 16. SDA
8. TMDS Data0 Shield 17. DDC/CEC Ground
9. TMDS Data0- 18. +5V Power
19. Hot Plug Detect
PIN Description PIN Description
1. Lane0(p) 11. GND
2. GND 12. Lane3(n)
3. Lane0(n) 13. Config1
4. Lane1(p) 14. Config2
5. GND 15. AUX_CH (n)
6. Lane1(n) 16. GND
7. Lane2(p) 17. AUX_CH (p)
8. GND 18. Hot Plug Detect
9. Lane3(n) 19. DP Power_Return
10. Lane3(p) 20. DP Power

Acer XB252Q Specifications

General

3D	No
Panel type	TN+Film
Screen shape	Flat
Display diagonal	24.5 \
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	240 Hz
Viewable size, vertical	303 mm
Viewing angle, vertical	160 °
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	544 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDMI	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
VGA (D-Sub) ports quantity	0
Pivot angle	-90 - 90 °
Cable lock slot	-
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
RMS rated power	4 W
Number of speakers	2
AC input voltage	120 - 230 V
Power consumption (off)	0.43 W
Power consumption (standby)	0.46 W
Power consumption (typical)	23 W
Product color	Black
Market positioning	Gaming
Cables included	DisplayPort, USB

Weight and Dimensions

Depth (without stand)	70.5 mm
Width (without stand)	557.9 mm
Height (without stand)	505.9 mm
Weight (without stand)	4350 g
