17 GB
Introduction
Technical Data
Nominal input voltage: 10,5 - 15,5 V / 15 A
Output capacity: 150 W
Peak output capacity: 300 Watt (for 0,1 Sec.)
Output voltage: 230 V ~
Efficiency: > 80 %
Output frequency: 50 Hz
USB-Output: 5,0 V
/ 0,5 A
Protection class: II /
Fuse: 15 A
Ambient temperature: 0 °C - 35 °C
Undervoltage protection: 10 V + / – 0,5 V
Overvoltage protection: 15,5 V
+ / – 0,5 V
Overload protection: 180 W, + / – 0,5 W
Overheating protection: > 65 °C
Dimensions: 147 x 88 x 27 mm
(L x W x H)
Weight: 280 g
Technical characteristics
The voltage converter has some technical
characteristics, in order to be protected and /
or the connected appliances.
Warning- and Protection display
In general errors are recognisable as follows:
- Red LED-display
6
- Peep- or butting tone
- Maintenance code (A) or protection code (P)
in the LED-display
2
Overvoltage protection:
If the input voltage is above 15,5 V (+ / – 0,5 V), a
buzzing tone sounds, the red LED-Display
6
shines, and P-4 is displayed on the LED-display
2
.
The voltage converter stops converting and the
external device will be switched off. If the voltage
drops below 14,5 V (+ / – 0,5 V), the voltage
converter starts the normal operation again.
Undervoltage protection (Battery display function,
Protection of the vehicle battery):
If the input voltage is under 11 V (+ / – 0,5 V), a
beep tone sounds, the red LED-display
6
lights
up and A-3 is indicated on the LED-Display
2
.
If the input voltage is under 10,5 V (+ / – 0,5 V), a
buzzing tone sounds, the red LED-display
6
lights
up and P-3 is displayed on the LED-display
2
.
The voltage converter stops converting and the
external device will be switched off.
If the voltage climbs above 12 V (+ / – 0,5 V), the
voltage converter starts the normal operation
again.
Short circuit protection:
If the connected device causes a short circuit, a
Code Red LED-Display Meaning Type of Warning
A - 1
Lights up
Overload warning
Peep toneA - 2 Overheating warning
A - 3 Undervoltage warning
P - 1
Lights up
Overload protection
Buzzing tone
Short circuit protection
P - 2 Overheating protection
P - 3 Undervoltage protection
P - 4 Overvoltage protection
