Operation / Error tracingSecurity / Before start-up / Operation
Place the 12 V-plug
3
of the voltage converter
into the 12 V-power source with a current min
15 A. Separate the 12 V-plug
3
always from the
power source, if you are not using the voltage
inverter.
After connection press the ON / OFF / MODE
button
1
for approx. 3 sec, now the
LED-display lights up:
Green LED-display
4 5
= Device is ready to
operate. Red LED-display
6
= Error! Examine the
12 V-plug
3
respectively see chapter „Error trac-
ing“.
WARNING!
Always separate the voltage converter from the
12 V-socket of the vehicle, before you switch on
the starter.
Never attach devices to the voltage converter
while driving and do not operate possibly attached
devices. Make sure that no devices are attached
to the voltage converter if attached to the
12 V power source, e.g. the cigarette lighter or
12 V-socket in a car.
Note: If the power supply is interrupted while
the voltage converter is in operation, you must
start it again. You can do this, by separating the
voltage converter again first and attaching it
again. After connecting the converter press and
hold the ON/OFF/MODE key
1
for approx. 3
seconds. The LED display will light and the self-
test will start as described above.
Operation
Attach external devices
Place the plug of the external device into the
output 230 V
9
on the voltage converter
and / or connect the external USB device to
at the USB output
8
.
Now power on the voltage converter by
pressing and holding ON/OFF/MODE
1
for
approx. 3 seconds. Once the self-test has
completed successfully the green LED
5
will
indicate that the converter is ready for use.
Please read the chapter „error tracing “if the
red LED-display lights up.
Now switch on the (external) devices con-
nected with the voltage inverter.
Note: If the power drawn is 35W or more, the
built-in fan will automatically switch on to pre-
vent the converter from overheating. With lower
power draws (< 35W) the fan will switch on
based on the temperature. Both outputs
8
and
9
can be used at the same time. The total nom-
inal capacity for both external devices, may not
exceed 150 W.
The nominal capacity of external device is shown
on the identification plate, which is in a certain
place on this external device. External devices like
electric motors, drills, electrical saws, refrigerators
and music systems, normally require a larger
nominal capacity when starting than indicated on
the identification plate. If the nominal capacity
is indicated in ampere only, multiply the value in
ampere by a factor of 230, in order to receive
the capacity in Watts.
For example: 0.4 A x 230 = 92 Watts
Exit 230 V
9
Use only external devices, which are either
equipped with bonding contact pins or European
fork wall plugs.
USB exit
8
Connect the external USB-device with the USB
output
8
and switch it on. The USB exit of this
voltage converter supplies a direct current of 5 V for
external USB devices (e.g. Lamps, fans, radios). The
USB output is always switched off, if the voltage
converter is connected to the 12 V-input socket.
WARNING!
The USB output on the voltage converter is not
intended for the data communication. Do not
attach a memory stick, MP3-Player or similar
external data memory devices. Do not connect
data communication cables to the USB exit!
