APPENDIX A
A-1
WATER HEATER MENU ITEM DESCRIPTIONS
MENU LEVEL & FUNCTION DESCRIPTION
OPERATING MENU
Active Setpoint This is the setpoint temperature to which the control
is operating when operating in the Constant Setpoint
or Remote Setpoint Mode. When in the Constant
Setpoint Mode, this value is equal to the Internal
Setpoint setting in the Configuration Menu. When in
the Remote Setpoint Mode, this value is the setpoint
equivalent to the remote analog signal supplied to the
unit.
Aux Temp For monitoring purposes only
Outdoor Temp Displayed only if outdoor sensor is enabled in the
Configuration Menu.
Flow Rate Flow rate in GPM is displayed only if flow sensor is
enabled.
Fire Rate Out Actual fire rate as shown on bar-graph. This function
must be factory-enabled.
Flame Strength Displays flame strength from 0 to 100%.
Run Cycles Displays the total number of run cycles from 0 to
999,999.
Run Hours Displays total run time of unit in hours from 0 to
999,999.
Fault Log Displays information on the last 9 faults.
