13
IFCLITY1106 - 5773010_01
COOLING CAPACITY - FCLI 32 / FCLI34
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [w] = Sensible cooling capacity
NB: The values in bold type indicate the nominal value.
If sensible power values are above the total cooling capacity, this
means that cooling is carried out without dehumidification.
In this case, only sensible power values are considered.
The cooling outputs of the table are at maximum speed (maximum
air flow).
To determine the cooling capacity based on the speed (air flow),
the values shown in the table must be multiplied by the following
factors (k):
FCLI 32 / FCLI34
Qv [m
3
/h] k (Pc) k (Ps)
Speed V3
600 1 1
Speed V2 410 0.77 0.82
Speed V1 300 0.61 0.65
Tw
[°C]
T [°C]
Ta W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
5
3
15 1526 1281 1519 1457 1526 1526 1574 1574 1722 1722 1797 1797
17 1969 1274 1965 1454 1961 1631 1957 1808 1951 1951 1953 1953
19 2448 1264 2442 1444 2436 1623 2430 1800 2424 1975 2420 2062
21 2955 1430 2947 1609 2939 1786 2931 1963 2929 2052
23 3497 1591 3493 1773 3481 1948 3477 2037
5
15 1317 1164 1347 1347 1404 1404 1502 1502 1653 1653 1728 1728
17 1785 1174 1781 1353 1775 1530 1783 1711 1803 1803 1823 1823
19 2270 1169 2266 1349 2262 1528 2258 1707 2254 1882 2246 1968
21 2784 1340 2777 1519 2773 1698 2767 1875 2765 1963
23 3335 1506 3327 1684 3319 1862 3315 1951
7
15 1056 1014 1154 1154 1261 1261 1407 1407 1564 1564 1643 1643
17 1518 1035 1515 1213 1540 1400 1589 1589 1654 1654 1698 1698
19 2056 1059 2052 1239 2048 1417 2040 1592 2044 1771 2048 1861
21 2587 1239 2579 1417 2575 1595 2571 1773 2567 1860
23 3145 1410 3141 1590 3133 1767 3129 1855
7
3
15 1185 1093 1201 1201 1266 1266 1417 1417 1567 1567 1641 1641
17 1631 1093 1627 1271 1621 1448 1620 1620 1649 1649 1670 1670
19 2108 1085 2104 1265 2100 1444 2092 1618 2090 1794 2084 1880
21 2614 1254 2606 1432 2092 1618 2595 1785 2593 1873
23 3156 1417 3153 1597 3145 1774 3141 1862
5
15 978 974 1064 1064 1188 1188 1344 1344 1498 1498 1573 1573
17 1417 984 1412 1161 1431 1345 1472 1472 1534 1534 1586 1586
19 1912 987 1908 1166 1906 1345
1900 1520
1898 1696 1902 1787
21 2428 1161 2424 1341 2420 1518 2412 1693 2411 1781
23 2978 1329 2974 1508 2967 1685 2963 1773
7
15 762 762 917 917 1083 1083 1247 1247 1407 1407 1485 1485
17 1069 812 1132 1014 1213 1213 1307 1307 1417 1417 1488 1488
19 1643 857 1643 1037 1638 1213 1654 1397 1692 1587 1714 1682
21 2203 1053 2199 1231 2195 1408 2191 1584 2191 1672
23 2769 1229 2765 1408 2757 1583 2757 1673
9
3
15 862 862 956 956 1109 1109 1261 1261 1411 1411 1485 1485
17 1268 910 1262 1085 1275 1266 1314 1314 1415 1415 1488 1488
19 1748 907 1744 1086 1740 1263 1734 1437 1730 1612 1733 1701
21 2252 1077 2246 1254 2242 1431 2238 1608 2234 1693
23 2796 1243 2790 1421 2784 1597 2781 1685
5
15 709 709 865 865 1027 1027 1186 1186 1341 1341 1417 1417
17 996 778 1039 970 1110 1110 1207 1207 1344 1344 1420 1420
19 1521 800 1518 978 1515 1155 1524 1335 1553 1519 1575 1575
21 2044 980 2040 1157 2037 1333 2033 1509 2031 1595
23 2598 1151 2595 1329 2587 1504 2587 1593
7
15 536 536 739 739 917 917 1086 1086 1249 1249 1328 1328
17 645 599 800 800 944 944 1088 1088 1251 1251 1330 1330
19 1159 637 1167 817 1213 1010 1284 1211 1368 1368 1415 1415
21 1775 859 1771 1035 1771 1212 1775 1390 1787 1482
23 2361 1045 2357 1222 2353 1398 2349 1485
COOLING CAPACITY CORRECTION FACTORS
