2 Product description
General information
AHT products comply with EU Directive 1907/2006
(REACH) for the registration, evaluation, approval
and limitation of chemical materials.
In the product design, the manufacturer has
considered the environmental and disposal-
friendliness of the device, in particular, for the
refrigerant propane (R-290) and the propellant
pentane (for the insulating foam). Propane does not
have any ozone depletion potential (ODP) and only a
very low greenhouse potential (GWP) of 3. The
refrigerant R-404A is recorded in the Kyoto Protocol.
It does not have any ozone depletion potential (ODP)
and has a greenhouse potential (GWP) of 3922.
Technical data
Important technical data can be found on the power
rating plate (see → Chapter 2.2.1).
External dimensions
Total weight of the
device
See → Device models
overview
Airborne noise
emissions
Emission sound pressure
level
< 70 dB(A)
M-package temperature class (product temperature
class) according to EN ISO 23953-2 (device-specific)
L1, S
Device series with mechanical controller
Series
Operational
area/
operating
mode
Adjustable levels
Level
(-)
Deep-freeze “-”
1-9
(V)
Deep-freeze “-”
1-9 (GEFRIEREN/FREEZING)
Cooling “+”
1-9 (KÜHLEN/CHILLING)
Device series with electronic controller
Series
Operational area/
operating mode
Adjustable
application
(-)
Deep-freeze “-”
A1 / A2
(S)
Meat cooling “S”
A3
(U)
Deep-freeze “-”
A1 / A2
Meat cooling “S”
A3
Cooling “+”
A4
Technical interfaces
Power supply (device-
specific; observe the
specifications on the power
rating plate, see → 2.2.1)
220-240 V 50 Hz
220-240 V 60 Hz
110-120 V 60 Hz
Plug types
Country-specific versions
are present
Connecting cable or IEC box with connecting
cable attached
Device
connecting cable
Labeling tag with
snowflake
Light
connecting cable
Labeling tag with lamp
Combined device / light
connecting cable
No labeling tag
Minimum requirements for the connecting cable
Minimum cross-section
Device: 1 mm² /18AWG
Light: 1 mm² /18AWG
Cabling
3-pin cable
External warning system
as plug connection on the
device, see → Chapter 9.3.
Connector: available as an
accessory from
maintenance service, see
→ Chapter 10.5
6-pin socket housing
Potential-free contacts
Load with max. 24 V / 2
A (safety low-voltage)
Electrical protection (see → Chapter 7.2)
Fuse
Rated current [A]
Triggering
characteri
stics
Type
Fault
current
[mA]
for
220-
240 V
for
110-
120 V
LS
(CB)
10 (1 device)
16 (2 devices)
15
C
(time-lag)
_
_
FI
(RCCB/
GFCI)
≥ 40
≥ 40
_
Surge
current-
resistant,
short-circuit
delayed
(e.g. G/AP-R)
30
FI-LS
(RCBO)
10 (1 device)
16 (2 devices)
15
C
(time-lag)
Surge
current-
resistant,
short-circuit
delayed
(e.g. G/AP-R)
30
Recommended light colors:
Customer-specific deviations possible.
Further information: Maintenance services (see →
Chapter 10.5).
Power rating plate and serial
number
When handling the device, the information on the
“power rating plate” must be observed. This is found
on a sticker at the rear side of the device (outside)
and contains important technical data about
Device name and device type,
Serial number (see → Chapter 10.4),
Climate class* (see → Chapter 1.3),
Rated voltage and rated frequency,
Rated current and rated consumption,
Refrigerant and amount used,
Net content,
Date of manufacture,
Test mark,
and other technical data.
*Examples of climate classes:
Description
LED
Fluorescent
tubes
Red light (meat)
076
-
Neutral white
4000 K
840/940
Cool white
5000 K
850/950
Ultra cool white
6500 K
865/965
