Airwell GC 24 User Manual

14-14
EXPLODED VIEWS AND SPARE PARTS LISTS
SM FLODCI 2-A.4 GB
14.14 Outdoor Unit: GC 24 Z
No. Item Description Quan.
1 465100000 Grill/ DCI Trio 1
2 4523652 PAINTED LEFT CABINET ASSY 1
3 4523758 Nut M8 left 1
4 452960400 Outdoor Fan 1
5 461600023 4-Way Valve Assy. 1
6 4522509 4-way Valve Coil 1
7 4526522 FOUR-WAY VALVE R410A 1
8 466130002R DC Motor 70W 8P 1
9 4522601 Right Handle 1
10 4523653 PAINTED RIGHT CABINET ASSY 1
11 4526775 Compressor Top Thermistor(CTT) 1
12 452956500 OMT Thermistor(OMT) 1
13 452677601 Outdoor Coil Thermistor(OCT) 1
14 452809900 Base Plate Painting Assy. 1
15 460080000R Compressor Assy./ C-7RVN153H0W SANYO ShenYang) 1
16 452783600 Oil Separator Assy. 1
17 452783200 Liquid-gas Separator 1
18 453256100 Support Painting Support Assy./Gas-Liquid Separator 1
19 4526080 Valve plate paint assy 1
20 4526513 LOW PRESS VALVE (R410A) 1
21 4526514 Hight press valve(R410A) 1
22 4523654 PAINTED RIGHT BACK CABINET ASSY 1
23 4522602 Valve Cover 1
24 4518950 Filter Drier BFK-053S 1
26 204107 Cable clip Nylon 2
27 467420003 7 Poles Terminal Block 1
28 464280001 Terminal Plate/ DCI 24Z 1
29 4526215 Electronic expansion valve ZDPF(L)-1.6C-01-RK for R410A 1
30 4526216 EEV COIL QA(L)12-MD-02 1
31 462300002 Condenser Assy. 1
32 453175500 Guard Net Painting Assy. 1
33 453083800 Support/OAT 1
34 4526396 Choke Assy.167-021-01 1
35 464730006 Partition Plate Assy./DCI 24Z 1
36 467300082R Controller/Outdoor Unit DCI 3.0KW(English) 906A-361-00 1
37 452888500 Motor Support 1
38 464250044 Connect Plate/Controller DCI 24Z 1
39 452841100 Earth wire 3
39 4516540 Earth wire 2
40 453238900 Sensor/OAT 1
41 4523657 PAINTED TOP COVER ASSY 1
42 4522600 Left Handle 1
43 467300114R DCI 3.0KW EMI Fillter Board 901A-574-00 1
