7-1
ELECTRICAL DATA
SM FLODCI 2-A.4 GB
7. ELECTRICAL DATA
7.1 Single Phase Unit
Model FLO 18 FLO 21 FLO 24 / 30
Power Supply 1 PH ,220-240VAC ,50HZ
Connected to To indoor To outdoor
Maximum Current 13.5A 15A 15.7A
Inrush Current \
(a)
45 A <35A
Starting Current\
(b)
13.5 A 15A 15.7A
Circuit Breaker 20 A
Power Supply 3 X 2.5 mm²
Interconnecting cable 4 X 2.5 mm²
(a) Inrush current is the current when power is up (charging the DC capacitors
at outdoor unit controller).
(b) Starting current is the current at compressor start up.
NOTE
Power wiring cord should comply with local lows and electrical
regulations requirements.
