Airwell GC 9 DCI User Manual

2-1
PRODUCT DATA SHEET
SM PNXADCI 1-A.1 GB
2. PRODUCT DATA SHEET
2.1 PNXA 9 DCI
Model Indoor Unit PNXA 9 DCI
Model Outdoor Unit GC 9 DCI R410A
Installation Method of Pipe Flared
Characteristics Units Cooling Heating
Capacity
(1)
Btu/hr 8530(4780-12280) 10240(5120-17060)
kW 2.5(1.4-3.6) 3.0(1.5-5.0)
Power input
(1)
kW 0.50(0.42-1.0) 0.60(0.39-1.6)
EER (Cooling) or COP(Heating)
(1)
W/W 5.00 5.00
(QHUJ\HI¿FLHQF\FODVV AA
Power supply
V 220-240
Ph 1
Hz 50
Rated current A 2.2 2.7
Power factor 0.97 0.97
Prated (IDU) W 32
Prated (IDU+ODU) W 1600
Starting current A 10.5
Circuit breaker rating A 15
INDOOR
Fan type & quantity &URVVÀRZ[
Fan speeds H/M/L RPM 1050/900/800
$LUÀRZ
(2)
H/M/L m3/hr 530/430/330
([WHUQDOVWDWLFSUHVVXUH Min Pa 0
Sound power level
(3)
H/M/L dB(A) 51/ - /39
Sound pressure level
(4)
H/M/L dB(A) 39/ - /26
Moisture removal l/hr 1
Condenstate drain tube I.D mm 16
Dimensions :[+[Dmm [[
Net Weight kg 11.5
Package dimensions :[+[Dmm [[
Packaged weight kg 14
Units per pallet units 28
Stacking height units 7 levels
OUTDOOR
Refrigerant control (OHFWURQLFDO([SDQVLRQValve
Compressor type,model Single Rotary DC Inverter,Panasonic 5RS102XAB
Fan type & quantity 3URSHOOHU[
Fan speeds H RPM 830
$LUÀRZ H m3/hr 1780
Sound power level H dB(A) 61
Sound pressure level
(4)
H dB(A) 51
Dimensions :[+[Dmm [[
Net Weight kg 38
Package dimensions :[+[Dmm [[
Packaged weight kg 42
Units per pallet Units 9
Stacking height units 3 levels
Refrigerant type R410A
Standard charge kg(7.5m) 1.1
Additional charge No need
Connections between units
Liquid line In.(mm) 1/4"(6.35)
Suction line In.(mm) 3/8"(9.53)
0D[WXELQJOHQJWhm. 0D[
0D[KHLJKW
difference
m. 0D[
Operation control type Remote control
Heating elements (Option) kW
Others
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN 14511.
(2) $LUÀRZLQGXFWHGXQLWVDWQRPLQDOH[WHUQDOVWDWLFSUHVVXUH
(3) Sound power in ducted units is measured at air discharge.
(4) Sound pressure level measured at 1 meter distance from unit.
