GB
Translation of original user instructions
26
Petrol lawnmower
Initial startup
Caution!
The equipment should not be used if the cutting
gear and/or fastenings are loose, damaged or
worn.
Carry out a visual inspection before each start-
up.
The camera symbol on the following page refers
to the illustrations on Page 4–7.
Adjusting the cutting height
Caution - Risk of injury!
Adjust the cutting height only with the motor
switched off and when the mower blade has
come to a standstill.
▪ Always set all the wheels to the same cutting
height.
▪ Cutting height adjustment depends on the
particular model.
Central adjustment (
1)
1. Press and hold the central height adjustment knob
(
1/1).
For shorter grass, press the central adjustment
handle downward (
1/2)
For longer grass, pull the central adjustment
handle upward (
1/2)
The central height adjustment level is indicated
(
1/3)
2. Release the knob at the desired cutting height.
Axle adjustment or central adjustment (
2, 3)
1. To release the lever, press to the side and hold.
2. Push the lever to the left or right to select the
desired cutting height.
3. Let the lever click into position.
4. Check that all wheels are set to the same position.
Quick adjustment of individual wheels
or axle adjustment (
4)
1. To release the lever, press to the side and hold.
2. Push the lever to the left or right to select the
desired cutting height.
3. Let the lever click into position.
4. Check that all wheels are set to the same position.
Individual wheel adjustment ( 5)
1. Loosen the wheel bolt.
2. Insert the wheel bolt in the hole corresponding to
the desired cutting height.
3. Tighten the wheel bolt.
4. Check that all wheels are set to the same position.
Central axle adjustment ( 6)
1. Place a thumb at each end of the axle.
2. Place the ngers under the mower housing.
3. Using both thumbs, press the axle out of its present
height setting notch.
4. Using both thumbs, push the axle to the desired
height setting notch, then allow it to engage.
5. Check that all wheels are set to the same position.
