Small Form-Factor Pluggables (SFPs) Bi-directional 100 FX Ethernet Transceivers
OmniSwitch Transceivers Guide June 2007 page 1-7
Bi-directional 100 FX Ethernet Transceivers
SFP-100-BX20LT
100Base-BX SFP optical transceiver with an SC type interface. This bi-directional transceiver is designed for
use over single mode fiber on a single strand.
Connector Type SC
Standards Supported 802.3ah, SFP MSA, ITU-T G.983
Connections Supported 100Base-BX
Fiber Type SMF
Wavelength Transmit: 1550 mm
Receive: 1310 nm
Average Power Output -14 to -8 dBm
Receiver Sensitivity -32 dBm
Transmission Distance ~20 km
Maximum Power Output 3 mW
Maximum Pulse Duration 5 ns
Notes Designed for use with SFP-100-BX20NU
SFP-100-BX20NU
100Base-BX SFP optical transceiver with an SC type interface. This bi-directional transceiver is designed for
use over single mode fiber on a single strand
.
Connector Type SC
Standards Supported 802.3ah, SFP MSA, ITU-T G.983
Connections Supported 100Base-BX
Fiber Type SMF
Wavelength Transmit: 1310 nm
Receive: 1550 nm
Average Power Output -14 to -8 dBm
Receiver Sensitivity -32 dBm
Transmission Distance ~20 km
Maximum Power Output 3 mW
Maximum Pulse Duration 5 ns
Notes Designed for use with SFP-100-BX20LT
