Alcatel-Lucent OmniSwitch 6800 Series User Manual

100 FX Ethernet Transceivers Small Form-Factor Pluggables (SFPs)
page 1-8 OmniSwitch Transceivers Guide June 2007
100 FX Ethernet Transceivers
SFP-100-LC-MM
100Base-FX SFP optical transceiver with an LC type interface. This transceiver is designed for use over multi-
mode fiber.
Connector Type LC
Standards Supported 802.3u, SFP MSA
Connections supported 100Base-FX
Fiber Type MMF
Wavelength 1300 nm
Optical Power Output -19 to -14 dBm
Optical Power Input -31 to -14 dBm
Transmission Distance -
Maximum power output 3 mW
Maximum pulse duration 5 ns
Notes
SFP-100-LC-SM15
100Base-FX SFP transceiver with an LC type interface. This transceiver is designed for use over single mode
fiber.
Connector Type LC
Standards Supported 802.3u, SFP MSA
Connections Supported 100Base-FX
Fiber Type SMF
Wavelength (nm) 1300 nm
Optical Power Output -15 to -8 dBm
Receiver Sensitivity -31 dBm
Transmission Distance ~15 km
Maximum power output 3 mW
Maximum pulse duration 5 ns
Notes
