Connecting a DC Power Source
The DC power supply on your switch contains a power connector with three (3) square slots for connect-
ing the positive, negative, and ground wires from a DC power source.
OmniSwitch DC Power Supply Connector
Side Screws for Connector Removal
DC Power Connectors
+ -
