Alienware m15 R2 User Manual

Table 11. Keyboard specifications(continued)
Description Values
Shortcut keys
Some keys on your keyboard have two symbols on them. These
keys can be used to type alternate characters or to perform
secondary functions. To type the alternate character, press Shift
and the desired key. To perform secondary functions, press Fn
and the desired key.
NOTE: You can define the primary behavior of the
function keys (F1–F12) changing Function Key Behavior
in BIOS setup program.
Keyboard shortcuts
Camera
Table 12. Camera specifications
Description Values
Number of cameras
One camera
Type
HD RGB camera
Location
Front camera
Sensor type
CMOS sensor technology
Resolution:
Still image
0.92 megapixel
Video
1280 x 720 (HD) at 30 fps
Diagonal viewing angle
74.9 degrees
Touchpad
Table 13. Touchpad specifications
Description Values
Resolution:
Horizontal
1217
Vertical
681
Dimensions:
Horizontal
105 mm (4.13 in.)
Vertical
60 mm (2.36 in.)
Touchpad gestures
For more information about touchpad gestures for Windows 10, see the Microsoft knowledge base article 4027871 at
support.microsoft.com.
13

Alienware m15 R2 Specifications

General

Color name	Lunar Light
Form factor	Clamshell
Product type	Laptop
Product color	Black, White
Market positioning	Gaming
Panel type	WVA
Pixel pitch	0.17925 x 0.17925 mm
LED backlight	Yes
Pixel density	141 ppi
Display diagonal	15.6 \
Display brightness	300 cd/m²
Native aspect ratio	16:9
Display response rise/fall	19 ms
Motherboard chipset	Intel® HM370
Internal memory	16 GB
Memory clock speed	2666 MHz
Memory form factor	On-board
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
SSD form factor	M.2
Total storage capacity	512 GB
Number of SSDs installed	1
Audio chip	Realtek ALC3281-CG
Speaker power	2 W
Number of built-in speakers	2
Front camera HD type	HD
Video capturing speed	30 fps
Front camera resolution	1280 x 720 pixels
Front camera signal format	720p
Front camera resolution (numeric)	0.92 MP
MIMO type	Multi User MIMO
Antenna type	2x2
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet LAN data rates	1000, 2500 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	Touchpad
Keyboard language	UK English
Keyboard backlit color	Various
Battery weight	320 g
Battery voltage	11.4 V
Battery capacity	76 Wh
Battery recharge time	4 h
Number of battery cells	6
Processor ARK ID	191045
Processor package size	42 x 28 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
AC adapter power	180 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	9.23 A
AC adapter output voltage	19.5 V
Cable lock slot type	Noble
Operating shock	110 G
Operating altitude	-15.2 - 3048 m
Non-operating shock	160 G
Operating vibration	0.66 G
Non-operating altitude	-15.2 - 10668 m
Non-operating vibration	1.3 G
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %
EPEAT rating	90.77 %
Tjunction	100 °C
Processor cache	12 MB
Processor model	i7-9750H
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor socket	BGA 1440
Processor threads	12
Processor codename	Coffee Lake
Processor frequency	2.6 GHz
Processor cache type	Smart Cache
Configurable TDP-down	35 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	4.5 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
Maximum number of PCI Express lanes	16
CUDA cores	1920
On-board graphics card ID	0x3E9B
Discrete graphics card model	NVIDIA® GeForce RTX™ 2060
On-board graphics card model	Intel® UHD Graphics 630
Discrete graphics card memory	6 GB
Discrete graphics memory type	GDDR6
Maximum on-board graphics card memory	64 GB
On-board graphics card OpenGL version	4.5
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Bundled software	Financial Tracker & Retail Information
Operating system language	English
Pallet width	1000 mm
Pallet length	1200 mm
Pallet weight	197960 g
Quantity per pallet	40 pc(s)
Pallet volume weight	75000 g
Quantity per pallet layer	20 pc(s)
Number of layers per pallet	2 pc(s)
Quantity per intermodal container (20ft)	800 pc(s)
Quantity per intermodal container (40ft)	1680 pc(s)
Package depth	455 mm
Package width	408 mm
Package height	117 mm
Package weight	4750 g
Package material	Corrugated cardboard, Polypropylene (PP)
Other materials content per package	117 g
Polypropylene (PP) content per package	19 g
Corrugated cardboard content per package	1338 g
Corrugated cardboard content per box for accessories	200 g
High-density polyethylene (HDPE) content per package	0 g
Corrugated cardboard content per shipping (inner) case	945 g
Corrugated cardboard content per sleeve for accessories	193 g

Weight and Dimensions

Depth	276 mm
Width	360.5 mm
Weight	2160 g
Height (rear)	19.5 mm
Height (front)	17.9 mm
